To provide high-quality weighing instrument products for global customers
- Product Feature
- Technical Index
-
- Commodity name: HT9800-T3 Weighing Indicator
Material: ABS Plastic Dimension: 250x160x150mm
Unique animal weighing technology
Piece counting function
RS232 interface, with electrostatic protection, continuous output, MODBUS-RTU, cancommunicate with the host computer or external thermal printers or big screen display
It can print the record format or duplicate format
Manual/automatic printing, print total
Transformer or power board supply optional
RS485 interface with electrostatic protection (Optional)
Wireless function (Optional, use with wireless transmission box)
Check weight function (Hi, Ok, Lo), can connect to 3 color alarm light (Optional)
Bluetooth (Optional)
Wall-Hanging/Rotating bracket (Optional)
-
Input signal range -19~+19mV AD conversion 20 bit Sigma-Delta analog to digital AD sampling frequency 3.84kHz Load cell excitation voltage DC5V/300mA Display 6 digits 1.2 inches high, LED display Division number of the display ≤100000d Serial port RS232 interface,RS485 optional Working temperature -10~+40°C Storage temperature -25~+55℃ Relative humidity ≤85% Power supply mode AC87~242V/AC220V;built-in DC6V/4.5Ah lead-acid battery
HT9800-T3 Weighing Indicator
